HOJE High temperature resistance double row spherical roller
bearing 241/950
HOJE High temperature resistance double row spherical roller
bearing 241/950
| Model |
Dimensions | Weight |
| d | D | B |
| 241/950 | 950mm | 1500mm | 545mm | 3535kg |
HOJE High temperature resistance double row spherical roller
bearing 241/950
Spherical roller bearings have two roller to mainly take radial
load,but also able to withstand the axial load in either
direction.High radial load capacity,especially sutiable for work
overload or vibration load,but can not afford the pure axial
load.This kind of bearing outer ring raceway is spherical
shape,aligning performance is good,can compensate concentricity
error.
HOJE High temperature resistance double row spherical roller
bearing 241/950
HOJE Manufacture series:
CC Design Spherical Roller Bearings
CA Design Spherical Roller Bearings
MB Design Spherical Roller Bearings
E Design Spherical Roller Bearings
HOJE High temperature resistance double row spherical roller
bearing 241/950
Suffix Number:
K:tapered bore,taper 1:12
K30:tapered bore,taper 1:30
CC:Two window-type steel cages,flangeless inner ring and guide ring
centered on the inner ring.
CA:One-piece machined brass cage,double-pronged,retaining flanges
on the inner ring ang guide ring centred on the inner ring.
E:For bearings with a bore diameter d≤65mm,Two pressed window-type
steel cages,flangeless inner ring and guide ring centred on the
inner ring (fig).For bearings with a bore diameter d≥65mm,Two
presseed window-type stel cages,flangeless inner ring and guide
ring centred on the cages.
MB:Solid brass cage,guidance on thge inner ring.
HOJE High temperature resistance double row spherical roller
bearing 241/950
Manufacture Size:Inner dia 20mm-outer Dia 600m
HOJE High temperature resistance double row spherical roller
bearing 241/950
Main application:
Papermaking machinery,deceleration devices,railkway vehicle
axle,rolling mill gearbox bearing,rolling mill roller
crusher,vibrating screen,printing machinery,wood working
machinery,various type of industrial gear reducer.
HOJE High temperature resistance double row spherical roller
bearing 241/950
ABOUT US :
HOJE Bearing Co., Ltd. is a professional spherical roller bearing
manufacturer .
Our company is engaged in the exported bearings.
We are engaged in the production of quality bearings,We can supply
various kinds of bearings according to customers' requirements. Our
products enjoy great popularity in the worldwide markets, like
Asia, Europe and the USA.
Our products are extensively used in machinery, excavator,
hydropower, engineering, railways, automobiles, electric power,
textiles, metallurgy, mine, papermaking, sports equipment and
precision instruments.
HOJE High temperature resistance double row spherical roller
bearing 241/950
HOJE company advantage :
| 15 years of export experience |
| stable cooperation with 35 countries and regions |
| 20000 kinds of product model to provide you more choices |
| $1500000 fixed inventory to shorten delivery time |
| many years of OEM and ODM service experience |
| ISO 9001 and SGS certification |
HOJE High temperature resistance double row spherical roller
bearing 241/950
HOJE company Service:
1,High quality
Only offer high quality products, long time, low noisy, high
precision! Customer's approval is our ultimate goal!
2,Deliver On Time
Rich stock and strong capability of production, never fail customer
with delivery time!
3,After-Sale Service
Full responsibility for the after-sale cargo, always being
customer's reliable partener in China!
HOJE High temperature resistance double row spherical roller
bearing 241/950
We can also provid other spherical roller bearings :
| Spherical Roller Bearing | | | | |
| Model | Dimesion(mm) | weight |
| d | D | T | |
| 22206CAW33 | 30.000 | 62.000 | 20.000 | 0.270 |
| 22206CCW33 | 30.000 | 62.000 | 20.000 | 0.270 |
| 22206MBW33 | 30.000 | 62.000 | 20.000 | 0.270 |
| 22207CAW33 | 35.000 | 72.000 | 23.000 | 0.430 |
| 22207CCW33 | 35.000 | 72.000 | 23.000 | 0.430 |
| 22207MBW33 | 35.000 | 72.000 | 23.000 | 0.430 |
| 22208CAW33 | 40.000 | 80.000 | 23.000 | 0.510 |
| 22208CCW33 | 40.000 | 80.000 | 23.000 | 0.510 |
| 22208MBW33 | 40.000 | 80.000 | 23.000 | 0.510 |
| 22209CAW33 | 45.000 | 85.000 | 23.000 | 0.540 |
| 22209CCW33 | 45.000 | 85.000 | 23.000 | 0.540 |
| 22209MBW33 | 45.000 | 85.000 | 23.000 | 0.540 |
| 22210CAW33 | 50.000 | 90.000 | 23.000 | 0.600 |
| 22210CCW33 | 50.000 | 90.000 | 23.000 | 0.600 |
| 22210MBW33 | 50.000 | 90.000 | 23.000 | 0.600 |
| 22211CAW33 | 55.000 | 100.000 | 25.000 | 0.820 |
| Spherical Roller Bearing | | | | |
| Model | Dimesion(mm) | weight |
| d | D | T | |
| 22206CAW33 | 30.000 | 62.000 | 20.000 | 0.270 |
| 22206CCW33 | 30.000 | 62.000 | 20.000 | 0.270 |
| 22206MBW33 | 30.000 | 62.000 | 20.000 | 0.270 |
| 22207CAW33 | 35.000 | 72.000 | 23.000 | 0.430 |
| 22207CCW33 | 35.000 | 72.000 | 23.000 | 0.430 |
| 22207MBW33 | 35.000 | 72.000 | 23.000 | 0.430 |
| 22208CAW33 | 40.000 | 80.000 | 23.000 | 0.510 |
| 22208CCW33 | 40.000 | 80.000 | 23.000 | 0.510 |
| 22208MBW33 | 40.000 | 80.000 | 23.000 | 0.510 |
| 22209CAW33 | 45.000 | 85.000 | 23.000 | 0.540 |
| 22209CCW33 | 45.000 | 85.000 | 23.000 | 0.540 |
| 22209MBW33 | 45.000 | 85.000 | 23.000 | 0.540 |
| 22210CAW33 | 50.000 | 90.000 | 23.000 | 0.600 |
| 22210CCW33 | 50.000 | 90.000 | 23.000 | 0.600 |
| 22210MBW33 | 50.000 | 90.000 | 23.000 | 0.600 |
